TROUBLE SHOOTING OF SOLAR LED STREET LIGHTING

0 comments

Problem

Problem Cause

Solution

Lamp does light up at all

Ambient light is much stronger

The light source will start automatically when the ambient light dims to a certain degree

Light source is damaged

Replace it with the same light source

The output circuit is open, short, or grounded

Check the output circuit connection

The connection between the storage battery's terminals is an open circuit

Check the connection between the storage battery's terminals and make sure it is okay.

The controller is damaged

Repair the controller or replace it with the same model controller.

Lamp works irregularly or shuts off too soon

The solar panel is covered by other things

Clean the solar panel.

The voltage of the storage battery is below 11.1V (22V for 24V system)

1. If the low voltage is caused by too many rainy days, it will recover automatically when the sun returns.

2. Check the connection of the solar panel

3. Check the battery connection



LED indicator

Indication

content

Status

Function

Remote control system status

 sokoyo co ltd









Solar panel indication



Steady on

Solar panel voltage is higher than light control voltage



Idle



Off

Solar panel voltage is lower than light control voltage



Idle

Slow flash

In charging

Charging

Double flash

Battery is fully charged

Fully charged



Quick flash

Lithium battery BMS protection Battery overvoltage; PV panel overvoltage Over temperature (ambient temperature)

E-BMS Battery overvoltage PV panel overvoltage

Over temperature

TENKOO









Battery indication

Steady on

Battery works properly

Idle



Off

Battery is not connected or lithium battery protection

board overdischarge protection



/

Quick flash

Battery over-discharge

Over discharge

Single flash (One flash per 10 seconds)



Overdischarge, sleep



/

 sokoyo co ltd







Load indication

Steady on

Load is turned on

Discharging

Off

Load is turned off

Idle

Slow flash

Load is open circuited

Open circuit

Quick flash

Load is short circuited

Short circuit
